Solar wall luminaire
Luminaire Configurator
Please make a selection in each field. Then click "Specific downloads & enquiry list" to get downloads for the configured luminaire, or to add the luminaire to the request list.
Indirect distribution. Acrylic cover in opal.
Passive cooling system made of aluminum. Luminaire housing made of sharp-edged aluminum profile. Surface powder-coated in white, black or RAL.
For wall mounting.
LED Type 13
Small Flux
low power
LED Type 14
Mid Flux
optimised power
LED Type 15
High Flux
high power
H 45 mm
B 120 mm
L 590-1710 mm
Article
LED Type
3000 K
4000 K
Power
Länge 590 mm
93532.
13
1380 lm
1440 lm
12 W
14
1940 lm
2010 lm
15 W
15
2750 lm
2860 lm
20 W
Länge 870 mm
93533.
13
2080 lm
2160 lm
16 W
14
2910 lm
3020 lm
21 W
15
4130 lm
4290 lm
29 W
Länge 1150 mm
93534.
13
2770 lm
2880 lm
20 W
14
3880 lm
4030 lm
27 W
15
5500 lm
5720 lm
37 W
Länge 1430 mm
93535.
13
3460 lm
3600 lm
24 W
14
4860 lm
5040 lm
33 W
15
6880 lm
7150 lm
46 W
Länge 1710 mm
93536.
13
4160 lm
4320 lm
28 W
14
5830 lm
6040 lm
38 W
15
8260 lm
8580 lm
54 W
► | Example Article-Number-Key |
